Sany SR235 drilling rig
≈ ₱6,543,000
Hunan
If you decide to buy equipment at a low price, make sure that you communicate with the real seller. Find out as much information about the owner of the equipment as possible. One way of cheating is to represent yourself as a real company. In case of suspicion, inform us about this for additional control, through the feedback form.
Before you decide to make a purchase, carefully review several sales offers to understand the average cost of your chosen equipment. If the price of the offer you like is much lower than similar offers, think about it. A significant price difference may indicate hidden defects or an attempt by the seller to commit fraudulent acts.
Do not buy products which price is too different from the average price for similar equipment.
Do not give consent to dubious pledges and prepaid goods. In case of doubt, do not be afraid to clarify details, ask for additional photographs and documents for equipment, check the authenticity of documents, ask questions.
The most common type of fraud. Unfair sellers may request a certain amount of advance payment to “book” your right to purchase equipment. Thus, fraudsters can collect a large amount and disappear, no longer get in touch.
- Transfer of prepayment to the card
- Do not make an advance payment without paperwork confirming the process of transferring money, if during the communication the seller is in doubt.
- Transfer to the “Trustee” account
- Such a request should be alarming, most likely you are communicating with a fraudster.
- Transfer to a company account with a similar name
- Be careful, fraudsters may disguise themselves as well-known companies, making minor changes to the name. Do not transfer funds if the company name is in doubt.
- Substitution of own details in the invoice of a real company
- Before making a transfer, make sure that the specified details are correct, and whether they relate to the specified company.
Seller's contacts
+86 178 735...
Show
+86 178 7356 7073
China
Drilling rig parts
Type: Rotary Drilling Rig
Power Type: Diesel
Use: Construction
Voltage: 24V
Drilling Diameter: 1000mm
Drilling Depth: Max.70m
Place of Origin: Hunan, China
Weight: 35000 KG
Warranty: 1 Year
Brand Name: SANY
Dimension(L*W*H): 11,090 mm * 3,060 mm * 3,600 mm
RPM Range: 20-50 RPM
Max. output torque: 250 kN.m
Maximum Hoisting Capacity: 20 Ton
Maximum Feed Force: 230 kN
Max.pull-down piston push: 250 kN
Max.pulling force: 300 kN
Main winch wire rope dia.: 16 mm
Max.main winch line speed: 80 m/min
High Efficiency
· Large core parameters such as high torque and crowd force; fast line speed of main rope to ensure high drilling efficiency in hard soil layer; it is suitable for overpass, high-speed rail, large buildings and other large hole foundation fields.
Full Stroke Crowd
· Adopt a winch crowd system with long stroke, fast crowding, and rotary drive display function, suitable for all casing construction in the beach, pebble and backfill formation.
Economy and Energy Saving
· Power optimization control technology is adopted to distribute power in real-time with the smooth and fast response of composite action; moreover, it has high fuel efficiency and low comprehensive fuel consumption.
Step Drum
· Adopt step drum structure with a single layer to realize no crushing, no wear, and increase the service life of wire rope by 35%.
Intelligent Upgrade
· HD touch screen, 3ms refresh frequency, smooth animation display.
Convenience
· The rotary drive key bar is exposed for easy service and replacement; the main winching wire rope is fixed by a wedge, which is easy to disassemble and assemble. Some lubrication points are exposed for easy service.
Tipo: Máquina perforadora rotatoria
Tipo de potencia: Diesel
Uso: Construcción Construcción
Voltaje: 24V
Diámetro de perforación: 1000mm
Profundidad de perforación: Max.70m
Lugar de origen: Hunan, China
Peso: 35000 KG
Garantía: 1 año
Nombre de marca: SANY
Dimensión(L*W*H): 11,090 mm * 3,060 mm * 3,600 mm
Rango de RPM: 20-50 RPM
Máx. par de salida: 250 kN.m
Capacidad máxima de elevación: 20 Ton
Fuerza de avance máxima: 230 kN
Fuerza de empuje máx.del pistón: 250 kN
Fuerza de tracción máx.: 300 kN
Diámetro del cable del cabrestante principal: 16 mm
Velocidad máxima de la línea del cabrestante principal: 80 m/min
Alta eficiencia
- Parámetros de núcleo grande como alto par y fuerza de empuje; velocidad de línea rápida de cable principal para asegurar alta eficiencia de perforación en capa de suelo duro; es conveniente para paso elevado, ferrocarril de alta velocidad, edificios grandes y otros campos de cimentación de agujero grande.
Cabrestante de carrera completa
- Adoptar un sistema de cabrestante multitud con carrera larga, rápida multitud, y la función de visualización de accionamiento rotativo, adecuado para toda la construcción de revestimiento en la playa, guijarros y la formación de relleno.
Economía y ahorro de energía
- Se adopta la tecnología de control de optimización de potencia para distribuir la potencia en tiempo real con la respuesta suave y rápida de la acción compuesta; además, tiene una alta eficiencia de combustible y bajo consumo de combustible integral.
Tambor escalonado
- Adopta la estructura de tambor escalonado con una sola capa para realizar sin aplastamiento, sin desgaste, y aumentar la vida útil del cable de acero en un 35%.
Actualización inteligente
- Pantalla táctil HD, frecuencia de actualización de 3 ms, visualización de animaciones fluidas.
Conveniente
- La barra de accionamiento giratorio está expuesta para facilitar el servicio y la sustitución; el cable principal del cabrestante está fijado por una cuña, que es fácil de desmontar y montar. Algunos puntos de lubricación están expuestos para facilitar el servicio.
