This Okuma LT2000-2T1MY was manufactured in 2022. It features two 22KW spindles, a 32-station BMT55 turret, and an OSP-P300LA control system with OSP and ECO suites. It includes a Samsys short bar loader, high-pressure pump, and tank. The machine offers 4-axis machining capabilities with Y-axis in the upper turret and is equipped with a 15" color LCD TFT multi-touch screen. If you are looking to get high-quality turning capabilities consider the Okuma LT2000-2T1MY machine we have for sale. Contact us for more information.
Additional equipment
Automation: Samsys short bar loader
Extra Features: High-pressure pump & tank, high-pressure seal kit, workpiece removal arm, tool height correction in the Y-axis, coolant tank and pumps, detachable wired handwheel, tool monitoring, programmable face printing, and Hi-Cut Pro for driven tools
two BMT55 revolvers with 16 stations each
Machine Benefits
Technical Machine Benefits
Features: reduction of machine-related idle times, harmonic speed oscillation, automatic speed synchronization, and remote diagnostics during warranty
Machine hours: 2268
Z taper: 140 mm
Front bearing diameter: 100 mm
Torque: 183 nm
Y-axis: y-axis in the upper turret with a movement range of +50/-45 = 95 mm
Helical interpolation: available with x/y/z linear axes, including eccentric milling with x/y/c axes
Tool monitoring system
Tool corrections: 96 tool corrections per turret
Extra Information
Spindle Orientation: Electronic spindle orientation +/- 0.1
Memory: 2 GB part program memory with a maximum program length of 2 MB
Data Management: MacMan machine management with integrated production data acquisition

Control Unit
Control System: CNC double turning center with a control system featuring OSP suite with numerous apps and ECO suite energy-saving features
Display: 15" color LCD TFT with 3D color graphics and a multi-touch screen/panel
Operating System: Second Windows operating system for operation and data communication

Controller
Ports: 2 USB 2.0 ports on the control panel
Communication: Ethernet/LAN interface with browser and DNC-T1 for program transfer

Turret
Tool Stations: Upper and lower turrets each with 16 driven tool stations
Motor Power: 5.5 kW per motor
Speed Range: 50 - 6000 rpm
Torque: 22.5 Nm

Number of axes Upper turret: X/Y/Z/C (turret can be used both left and right, of course)
Number of axes:Sub-spindle (right): lower turret XZC (turret can be used both left and right)
chuck main spindle (left) Hainbuch mini 'Axzug' 65 (pull)
Maximum clamping diameter on the main chuck (65 mm)
chuck secondary spindle yes, Hainbuch mini 'Axfix' 65 (fixed, ideal for part relay into right hand spindle)
Maximum clamping diameter on the main chuck (65 mm)
Transformer included
Inspection is available from 2023. Machine is in great condition and within geometry
Maintenance protocol is available
application type: Turning
Location: Germany
machine type: Horizontal Turning Machine
Number of Axes: 2
Spindle Power: 11.5 kW
